                                                      Model:     HSC-1542CLDN



  • Introduction

GX Half-size CPU card, with LCD/CRT/SSD/LAN/4COM





  • Features

NS GX1 300MHz low-power CPU on board
Work in 0¡æ~60¡æ without fan,improved system reliability
Integrated SM722/SM712 Graphics accelerated controller , 4M independently display memory
Support multi TFT/DSTN LCD, LVDS(SMI 722)and TTL interface
10/100Mbps PCI Ethernet interface
4 channel parallel interface
+5V single power



  • Specifications

Bus type : Half-size ISA bus
Processor:low-power NS GX1 serial 300MHz CPU on board,without fans can work normally
System chipset: NS CS5530A chipset
System memory:1 144 SODIMM slot£¬up to 256MB SDRAM
BIOS: AMI PnP BIOS(2MB)
On-board video:SMI722/712 Mobile Computer Display Controller, 4MB SDRAM inside, Support CRT and multi LCD,with LVDS(SMI 722)ºÍTTL interface
On-board LAN: RTL 8100BL 10/100M Ethernet controller, RJ-45 interface
IDE controller:1 40-pin ATA-33 channel, support two IDE devices
Multi I/O interface:Two USB, one parallel interface, one PS/2 keyboard/mouse interface, four series interface,among them COM1¡¢COM3¡¢COM4 support RS-232,COM2 support RS-232/ RS-422/RS-485
Solid state disk interface:One CompactFlash slot

Watchdog timer: 1-255 minute programable
Extention bus: PC/104 slot
Power supply : Single +5V power£¬1.1A(typical 5V/1.3A)
Dimension :185mm¡Á122mm
Operation Temperature:0~60
°
Relative Humidity:5%~90%£¬non-condensing
